Product center
KW148M-C Performance parameters of binoculars with north
KW148M-C
Order inquiry
product description:
A good telescope of a high-quality brand uses strictly inspected optical glass and high-level optical processing. A great choice for enjoying the outdoors.
Technical Parameters:
| MODELS | |||||
| SPEC. | 7X50C | 10X50C | 7X35C | 8X42C | |
| POWER | 7X | 10X | 7X | 8X | |
| OBJ. LENS DIA. | mm | 50 | 50 | 35 | 42 |
| TYPE OF PRISM | Type / Material | Porro/BaK4 | Porro/BaK4 | Porro/BaK4 | Porro/BaK4 |
| PRISM COATING | Yes / No | Yes | Yes | Yes | Yes |
| NUMBER OF LENS | Pieces & Groups | 5Pcs/3Groups | 6Pcs/4Groups | 5Pcs/3Groups | 5Pcs/3Groups |
| LENS COATING | Part / Full / Multi | Multi | Multi | Multi | Multi |
| FOCUS SYSTEM | Cent. / Ind. / Fix | Lnd. | Lnd. | Lnd. | Lnd. |
| FOCUSING LENS | Eye. / Obj. / Int. | Eye. | Eye. | Eye. | Eye. |
| EXIT PUPIL DIAMETER | mm | 6.5mm | 4.7mm | 5mm | 5.3mm |
| EXIT PUPIL DIST. | mm | 24mm | 17.5mm | 21mm | 21mm |
| FIELD OF VIEW | Angel | 6.8° | 5.7° | 7.4° | 7.4° |
| Ft / 1,000Yds | 357Ft/1000Yds | 300Ft/1000Yds | 387Ft/1000Yds | 387Ft/1000Yds | |
| M / 1,000M | 119M/1000M | 100M/1000M | 129M/1000M | 129M/1000M | |
| MIN. FOCAL LENGTH | M / Ft. | 8.6M/28Ft | 8.6M/28Ft | 8.6M/28Ft | 8.6M/28Ft |
| RELATIVE BRIGHTNESS | 42.25 | 22.09 | 25 | 28.09 | |
| TWILIGHT INDEX | 18.71 | 22.36 | 15.65 | 18.33 | |
| RESOLUTION | |||||
| DIOPTER SYSTEM | |||||
| DIOPTER COMP. | ± Optic Degree | 5 DIOPTER | 6 DIOPTER | 5 DIOPTER | 5 DIOPTER |
| INTERPUPILLARY DIST | mm | 73mm to 55.5mm | 73mm to 55.5mm | 73mm to 55.5mm | 73mm to 55.5mm |
| Yes / No | Yes | Yes | Yes | Yes | |
| Yes / No | Yes | Yes | Yes | Yes | |
| Yes / No | Yes | Yes | Yes | Yes | |
| ZOOM SYSTEM | Type & Location | ||||
| WEATHER PROOF | Yes / No | Yes | Yes | Yes | Yes |
| WATER PROOF | Yes / No | Yes | Yes | Yes | Yes |
| NITROGEN FILLED | Yes / No | Yes | Yes | Yes | Yes |
| FOLDING EYECUPS | Yes / No | Yes | Yes | Yes | Yes |
| POUCH | Yes / No-Mat'l. | Yes | Yes | Yes | Yes |
| STRAP | Yes / No-Mat'l. | Yes | Yes | Yes | Yes |
| CLEANING CLOTH | Yes / No | Yes | Yes | Yes | Yes |
| SILICA GEL | Yes / No | Yes | Yes | Yes | Yes |
| UNIT DIMENSION | mm | 195 X194X76 | 190X194X76 | 146X186X73 | 165X190X73 |
| UNIT WEIGHT | gm / oz. | ||||
| GIFT BOX SIZE | mm | ||||
| INNER CARTON | Pieces / Size | ||||
| PIECES PER CARTON | Pieces | ||||
| SHIPPING CARTON | Size | ||||
| GROSS WEIGHT | Kg. / Pound | ||||
| NET WEIGHT | Kg. / Pound | ||||
